| 모델 번호.: | DS5600 | 인터페이스 유형: | USB |
|---|---|---|---|
| 스캔 속도: | 300은 / 초를 스캐닝합니다 | 스캔 요소: | CMOS |
| CPU: | 32개 비트 | 해결: | 2500 |
| 읽기 정밀도: | 3mil/0.076mm | 디코딩 속도: | 300 번 / Ｓ |
| 피사계 심도: | 10mm-600mm | 인쇄 대비: | 20% |
| 무게: | 110g | 차원: | L180mm * W60mm * H80mm |
| 전원 공급 장치: | DC 5V@80MA (작업) | 작동 온도: | -20ºC ~ 50ºC |
| 저장 온도: | -40ºC ~ 60ºC | ||
| 강조하다: | 1D barcode scanner with USB interface,DS5600 barcode scanner 300 scans/sec,high-speed 1D barcode scanner USB |
||
DS5220-1D is a high-performance 1D barcode scanner featuring advanced CCD image recognition technology. It reliably reads barcodes from paper, products, screens, and other media surfaces.
Ideal for manufacturing, warehousing, logistics, healthcare, retail chains, mobile payments, express delivery, inventory management, food traceability, and asset tracking applications.
| Scan Type | Linear CCD |
|---|---|
| Light Source | Visible red light, 625±10nm |
| CPU | 32-bit |
| Resolution | 2500 |
| Reading Precision | ≥3mil/0.076mm (PCS90%, Code 39) |
| Decoding Speed | 300 times/second |
| Depth of Field | 20mm-680mm |
| Scan Modes | Manual, Continuous, Auto Sense, Flashing, control command |
| Prompt Method | LED indicator, buzzer |
| Scan Angle | Pitch: ±60°, Roll: ±30°, Skew: ±60° |
| Print Contrast Signal | ≥20% |
| Ambient Light | Dark environment to indoor natural light |
| Supported Symbologies | UPC-A, UPC-E, EAN-8, EAN-13, ISSN, ISBN, Code 128, GS1-128, ISBT 128, Code 39, Code 93, Code 11, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, Standard 2 of 5 (IATA), Codabar (NW-7), Plessey, MSI Plessey, RSS, China Post, etc. |
| Weight | ≈160.8g (without cable) |
|---|---|
| Dimensions | 68.4mm × 170.6mm × 87.6mm |
| Communication | USB, USB-COM |
| Interface | USB, USB-COM |
| Power Supply | DC 5V@80mA (operating) |
| Operating Temperature | -20°C to 50°C |
|---|---|
| Storage Temperature | -40°C to 60°C |
| Humidity | 5% to 95% (non-condensing) |
| Transport Vibration Test | 10H@125RPM |
| Cable | USB Cable for connecting to host devices |
|---|---|
| RS232 Cable with USB power supply for host connection |
DYscan: As professional barcode scanner manufacturers with 18 years of field experience, we maintain strict quality control with dedicated QC teams and testing equipment including engine age tests, wire bend machines, switch life tests, and shock resistance tests. All products meet CE, FCC, and ROHS certifications.
DYscan: We conduct rigorous testing including 1 million wire bend tests and 1 million button press tests. Every device undergoes comprehensive testing before shipment.
DYscan: 12-month warranty coverage.
DYscan: Our assembly line production process ensures consistency, with each product tested at least 4 times before delivery.
DYscan: We provide OEM services including custom logos, packaging, and manuals. Our technical team supports ODM development projects.
DYscan: As a specialized scanner manufacturer, we maintain dedicated departments for R&D, production, testing, marketing, sales, and customer service to ensure comprehensive support.
DYscan: No drivers needed - our scanners support plug-and-play functionality with Windows, Mac OS, iOS, Linux, UNIX, and Android systems.
